1、概述
YDZ系列鉆孔機用恒功率變極多速三相異步電動機是為建筑行業基礎工程施工用鉆孔機配套的電動機，可廣泛用于城市、橋梁、港口、江河堤防等各種基礎施工工程所用鉆孔機的電力驅動。
YDZ系列電動機是利用改變定子繞組的接線方法以改變電動機的極數來實現變速的，電動機在兩種轉速下具有相同的功率。鉆孔機在施工過程中，可根據不同的工作狀態選擇電動機的轉速，從而達到提高施工高利率、加快工程建設速度的要求。電機也可做成單速。
YDZ系列電動機堵轉轉矩高，過載能力強，低速下較大轉矩倍數及堵轉轉矩倍數均超過3倍，能夠適應鉆孔機在各種地質條件下工作。在施工中如遇特殊復雜地層，可充分利用電動機的高起動轉矩和高過載能力，保證施工順利進行。
YDZ系列電動機具有較高的機械強度，可以承受施工作業中可能遇到的振動與沖擊。電動機防護等級為IP54，接線盒的防護等級為IP55?？蛇m應鉆孔機在各種工作環境下施工。
YDZ系列電動機絕緣等級為F級，具有較高的運行可靠性。
YDZ系列電動機安裝方式為V1安裝，接線盒位于非軸伸端，設有2個出線孔，出線孔方向朝下，便于電動機接線。
YDZ系列電動機帶有注、卸油裝置，電機維護方便。
YDZ系列電動機的額定電壓為380V，額定頻率為50Hz。
General
YDZ series constant-power change-pole multi-speed three phase induction motors are matched with the augers for the basic engineering of architecture. It can be as the auger power source for the architecture in city construction, bridge, port, embankment etc.
YDZ series motors may change the poles through changing the stator winding’s connection, in order to achieve multi-speed, and have the same power under the two kinds of speed. During the construction, the motors speed can be chosen according to the working state for the augers, so that it can improve the construction efficiency, fasten the construction speed and save energy. The motors can be made into one-speed motors too.
YDZ series motors have high locked-rotor torque, high overload capability, and the max and locked-rotor torque multiple being more than 3 times under low speed, so that they can accord with the working of augers under various conditions. If meeting special complex stratum, construction can be run because of the motors characteristic.
YDZ series motors can burden vibration and shock because of the higher mechanical intension. Motors degree of protection is IP54, IP55 for the terminal box. They are suitable for the augers working under various surroundings.
YDZ series motors insulation class is F, and they have high running reliability.
YDZ series motors basic mounting type is V1. Terminal box is at no-driving end, and there are two lead in wire entries adown in order to connect winding easily.
The rated voltage is 380V and the frequency is 50 Hz.
3、訂貨須知 Notes for ordering
1)、訂貨時須注明電動機型號、功率、電壓、頻率、轉速等。
2)、如有特殊要求，可與本公司協商訂貨。
1)、When ordering, Please record the type, rated power, rated voltage, rated frequency, speed, and so on.
2)、If you have special demands, please confer with us on your demands.
